Bianco Activ 515 SGE
  • Manoeuvering handles, ergonomic and stable, at the front and rear
  • Awning light (LED), switched twice
  • Bottle crate lid with gas-pressure damper, three-point locking
  • Brake lights integrated in upper position lights
  • Central locking system
  • Double-glazed, tinted hinged windows that can be operated with one hand and combined fly-screen/blackout roller blind
  • Entrance door with integrated and insulated access, waste collector and storage, tinted window and pleated blackout blind in the upper entrance door area
  • Exterior storage flap
  • External air vents on both sides
  • Forced ventilation according to EN standard 1645-1
  • Front part partly with LFI technology
  • Rear fog lamp(s)
  • Reversing lights (2 pieces)
  • Sandwich construction
  • Water tank filler cap with retaining strap
  • Wheel housings, fully insulated
  • "White" drawbar cover
  • "White" overrun device cover
  • Approval for 100 km/h
  • Automatic reversing
  • Brake AAA, self-adjusting (AL-KO)
  • Euro axle system (AL-KO)
  • Extended crank supports
  • Galvanised stable-form corner steadies
  • Increased load capacity due to reinforced chassis
  • Jockey wheel with load indicator
  • Low-profile tyres
  • Safety coupling AKS 3004 (AL-KO)
  • Shock absorber
  • System lightweight chassis, fully galvanised (AL-KO)
  • Carpet in the door sill with the Fendt-Caravan logo
  • Ceiling lamp (LED/12 V) with 2 circuits
  • Clothes rack in the sleeping area
  • Ergonomically shaped back padding
  • Folding sliding door
  • Furniture in "Tiberino decor", "Almena" or „Pula“
  • High-density seat upholstery
  • Indirect lighting (LED)
  • Lateral loading feature (with separate beds)
  • LED lighting
  • Leesspots 12V in rondzitgroep
  • Lift-O-Mat (single and double beds)
  • Mattresses: interior-sprung (single and double beds)
  • MINI and MIDI roof hood (Dometic) with crank, forced ventilation, integrated blackout pleated blind and roller fly screen
  • Reading spotlights (12 V) in the sleeping area
  • Slatted bed base with fully flexible and permanently elastic bridged joints and hardness adjustment (single and French beds)
  • Ventilated storage compartments with indirect ceiling lighting (LED)
  • Vinyl flooring, hard-wearing, easy to care for
  • Winter backrests
  • Absorption refrigerator (133 l when freezer compartment is removed), slim tower, that can be opened from both sides, with interior lighting
  • Bathroom lighting (LED/12 V)
  • Bathroom storage compartments with soft-close hinges
  • Brass kitchen mixer tap
  • Central washrooms with large wall units, generous shelves under the sink and an illuminated mirror
  • Comfort pleated roller blind on the kitchen window
  • Cutlery inserts with a soft-touch surface
  • Flush toilet with diode level indicator and holding tank (rollable)
  • Kitchen storage compartments with soft-close hinges
  • Kitchens with large drawers
  • Stainless steel sink with glass cover
  • Stove (3-burner) with safety pilot, automatic ignition, matt, enamelled stove grate, glass cover and separate sink with glass cover
  • Towel/clothes hooks and toilet paper holder
  • Washbasin in white with shelves, bathroom cabinet and illuminated mirror
  • Washroom window, hinged, made of frosted glass with blackout roller blind and roller fly screen
  • Waste collector integrated into the entrance door
  • Workplace lighting (LED)
  • Fresh water (fixed tank 10 d)/25 e) litres) with external filling
  • Fresh water level indicator
  • Mobile waste water tank (24 L)
  • TV cabling (230 V socket)
  • Fuse box (230 V) with residual current device (safety switch)
  • Smoke detector
  • Switch on the entrance door for the ceiling light and awning light
  • Switching power supply 350 W
  • Truma Combi 4 gas heaters with CP plus iNET ready digital control panel with air circulation and integrated hot water boiler (10 l capacity)
  • USB-C double socket(s)

Bianco Activ 515 SGE
  • Manoeuvering handles, ergonomic and stable, at the front and rear
  • Awning light (LED), switched twice
  • Bottle crate lid with gas-pressure damper, three-point locking
  • Brake lights integrated in upper position lights
  • Central locking system
  • Double-glazed, tinted hinged windows that can be operated with one hand and combined fly-screen/blackout roller blind
  • Entrance door with integrated and insulated access, waste collector and storage, tinted window and pleated blackout blind in the upper entrance door area
  • Exterior storage flap
  • External air vents on both sides
  • Forced ventilation according to EN standard 1645-1
  • Front part partly with LFI technology
  • Rear fog lamp(s)
  • Reversing lights (2 pieces)
  • Sandwich construction
  • Water tank filler cap with retaining strap
  • Wheel housings, fully insulated
  • "White" drawbar cover
  • "White" overrun device cover
  • Approval for 100 km/h
  • Automatic reversing
  • Brake AAA, self-adjusting (AL-KO)
  • Euro axle system (AL-KO)
  • Extended crank supports
  • Galvanised stable-form corner steadies
  • Increased load capacity due to reinforced chassis
  • Jockey wheel with load indicator
  • Low-profile tyres
  • Safety coupling AKS 3004 (AL-KO)
  • Shock absorber
  • System lightweight chassis, fully galvanised (AL-KO)
  • Carpet in the door sill with the Fendt-Caravan logo
  • Ceiling lamp (LED/12 V) with 2 circuits
  • Clothes rack in the sleeping area
  • Ergonomically shaped back padding
  • Folding sliding door
  • Furniture in "Tiberino decor", "Almena" or „Pula“
  • High-density seat upholstery
  • Indirect lighting (LED)
  • Lateral loading feature (with separate beds)
  • LED lighting
  • Leesspots 12V in rondzitgroep
  • Lift-O-Mat (single and double beds)
  • Mattresses: interior-sprung (single and double beds)
  • MINI and MIDI roof hood (Dometic) with crank, forced ventilation, integrated blackout pleated blind and roller fly screen
  • Reading spotlights (12 V) in the sleeping area
  • Slatted bed base with fully flexible and permanently elastic bridged joints and hardness adjustment (single and French beds)
  • Ventilated storage compartments with indirect ceiling lighting (LED)
  • Vinyl flooring, hard-wearing, easy to care for
  • Winter backrests
  • Absorption refrigerator (133 l when freezer compartment is removed), slim tower, that can be opened from both sides, with interior lighting
  • Bathroom lighting (LED/12 V)
  • Bathroom storage compartments with soft-close hinges
  • Brass kitchen mixer tap
  • Central washrooms with large wall units, generous shelves under the sink and an illuminated mirror
  • Comfort pleated roller blind on the kitchen window
  • Cutlery inserts with a soft-touch surface
  • Flush toilet with diode level indicator and holding tank (rollable)
  • Kitchen storage compartments with soft-close hinges
  • Kitchens with large drawers
  • Stainless steel sink with glass cover
  • Stove (3-burner) with safety pilot, automatic ignition, matt, enamelled stove grate, glass cover and separate sink with glass cover
  • Towel/clothes hooks and toilet paper holder
  • Washbasin in white with shelves, bathroom cabinet and illuminated mirror
  • Washroom window, hinged, made of frosted glass with blackout roller blind and roller fly screen
  • Waste collector integrated into the entrance door
  • Workplace lighting (LED)
  • Fresh water (fixed tank 10 d)/25 e) litres) with external filling
  • Fresh water level indicator
  • Mobile waste water tank (24 L)
  • TV cabling (230 V socket)
  • Fuse box (230 V) with residual current device (safety switch)
  • Smoke detector
  • Switch on the entrance door for the ceiling light and awning light
  • Switching power supply 350 W
  • Truma Combi 4 gas heaters with CP plus iNET ready digital control panel with air circulation and integrated hot water boiler (10 l capacity)
  • USB-C double socket(s)

Total length cm
751
Body length cm
637
Useful length cm
556
Total width cm
232
max. Height cm
266
Headroom cm
198
Sleeping spaces
4
Bed surface at front cm
140/121 x 210
Bed surface at rear cm
2 x 85 x 200
Bed surface in middle cm
-
Bunk bed surface cm
-
Technically permitted total mass kg
1700 g)
Dead weigh kgb
1368
Basic equipment kga
53
Mass in running the road kgc
1421
Vehicle load capacity kg approx.
279
Floor / roof / wall thickness mm
47 / 39 / 31
Tyresi
195/70 R 15 C
Single/tandem axle
single
Awning circumference cmv
1017
HINWEIS: bei folgenden Auflastung ändert sich das Vorzeltumlaufmaß:
1800 kg: Vorzeltumlaufmaß 1015 cm
1900/2000 kg: Vorzeltumlaufmaß 1019 cm
